Application

Process industry | Water and waste water
Chemical industry | Food and beverage industry
Low solids content media | sewage water pumps
Chemical standard pumps.

  Face Materials

Carbon / Ceramic
Carbon / Silicon Carbide
Silicon Carbide / Silicon Carbide
Tungsten Carbide/Tungsten Carbide

  Metal Parts

SS 316, SS 304.
Secondary Seal : PTFE, TTV,Viton

  Operating Range

Shaft Dia : 25 to 100 mm
Pressure : 8 Bars (max)
Temperature : -20 to +180 C
Velocity : Up to 20 m/sec

  Features

Single Acting | Unbalanced | Inside Mounted
Independent of Direction of Rotation
Wave Spring Loaded
