Application

Power plant technology | Chemical industry
Hot media | Highly viscous media
Special rotating equipment

  Face Materials

Carbon/ Silicon Carbide
Carbon/ Tungsten Carbide
Silicon Carbide/ Tungsten Carbide
Silicon Carbide/Silicon Carbide

  Metal Parts

SS316, Carpenter-42
Secondary Seal : Grafoil
Welded Bellows : AM 350

  Operating Range

Shaft Dia : 25 to 100 mm
pressure : 12 bar(max)
Temperature : -20 to +300C
Velocity : Up to 20 m/sec

  Features

For unstepped shafts | Single Seal
Balanced | Independent of direction of rotation
Metal bellows rotating
