Application

Pharmaceutical & Food Industries, Mixers & Agitator

  Face Materials

Carbon/ Silicon Carbide
Carbon/ Tungsten Carbide
Silicon Carbide/ Silicon Carbide

  Metal Parts

SS316, SS304, Hastelloy-C
Hastelloy-B, Monel, Alloy-20
Secondary Seal :Elastomers TCV

  Operating Range

Shaft Dia : 20 to 140 mm
Pressure : 8 Bars (max)
Temperature : Ambinent to +120 C
Speed : up to 275 rpm

  Features

Single Acting | Reverse Balanced
Outside Mounted | Dry Running
Independent of Direction of Rotation
