Application

Extremely Corrosive & Chemical Applications.

  Face Materials

GFT / Ceramic
Silicon Carbide / Ceramic
Carbon / Ceramic
Silicon Carbide / Silicon Carbide

  Metal Parts

SS 316, SS 304, Hastelloy-C.
Springs : Hastelloy-C, Alloy-20, Teflon Coated
Secondary Seal : PTFE Bellows

  Operating Range

Shaft Dia : 18 to 100 mm
Pressure : 6 Bars (max)
Temperature : -22 to +130 C
Velocity : Up to 20 m/sec

  Features

Single acting | Outside mounted
Independent of direction of rotation
