Application

Petrochemicals | Petroleum Refinery
General Chemicals | Light Hydrocarbons

  Face Materials

Carbon / Lecrolloy
Carbon / Ceramic
Carbon / Silicon Carbide
Silicon Carbide / Silicon Carbide
Tungsten Carbide/Tungsten Carbide

  Metal Parts

SS 316, SS 304, Hastelloy-C, Monel, Alloy-20
Secondary Seal : Elastomers (‘O’ Ring), Viton, Kalez, Chembraz, TCV, PTFE, GFT (Wedge)

  Operating Range

Shaft Dia : 16 to 100 mm
Pressure : 8 Bars (max)
Temperature : -30 to +180 C
Velocity : Up to 20 m/sec

  Features

Single acting | Unbalanced | Inside mounted
Independent of direction of rotation
