Application

Water and waste water | Food and beverage industry
Pulp and paper industry | Chemical industry
Submersible pumps | Oil applications

  Face Materials

Carbon / Ceramic
Carbon / Silicon Carbide
Silicon Carbide / Silicon Carbide

  Metal Parts

SS 316, SS 304
Secondary Seal :Nitrile, Viton, EPDM

  Operating Range

Shaft Dia : 12 to 100 mm
pressure : 6 bar(max)
Temperature : -20 to +140C
Velocity : Up to 20 m/sec

  Features

For plain shafts | Single and dual seal
Elastomer bellows rotating | Unbalanced
Independent of direction of rotation
No torsion on bellows
