Application

Water and waste water | Food and beverage industry
Chemical industry | Process industry
Water and waste water | Industrial pumps/equipment
Submersible pumps

  Face Materials

Carbon/ Silicon Carbide
Carbon/ Tungsten Carbide
Silicon Carbide/ Silicon Carbide

  Metal Parts

SS316, SS304,
Secondary Seal : Elastomer Bellow, Nitrile,
EPDM, Viton

  Operating Range

Shaft Dia : 16 to 80 mm
Pressure : 6 Bars (max)
Temperature : -20 to +140 C
Velocity : Up to 20 m/sec

  Features

Single Acting | Single helical coil Spring
Torque Transmission by Elastomer Bellow
