Application

Petrochemicals, General & Light Hydrocarbons
Emitting Vapour & Phamaceutical Industies

  Face Materials

Carbon/ Ceramic
Carbon/ Silicon Carbide
Carbon/ Tungsten Carbide

  Metal Parts

SS316, SS304, Hastelloy-C
Hastelloy-B, Monel, Alloy-20
Carbon Steel
Secondary Seal : Inboard -PTFE, GFT
Outboard-Elastoners
PTFE, GFT

  Operating Range

Shaft Dia : 25 to 150 mm
Pressure : 35 Bars (max)
Temperature : Ambinent to +200 C
Speed : 400 rpm

  Features

Single Acting | Unbalanced | Single helical coil
Independent of Direction of Rotation
Torque Transmission by Elastomer Bellow
