Application

Sugar industry | Pulp and paper industry
Dirty, abrasive and solids containing media
Thick juice (70 ... 75 % sugar content)
Food Industry

  Face Materials

Carbon / Ceramic
Carbon / Silicon Carbide
Silicon Carbide / Silicon Carbide
Tungsten Carbide/Tungsten Carbide

  Metal Parts

SS 316, SS 304, Hastelloy-C
Secondary Seal : Elastomers, TCV, Karlez, Chemraz

  Operating Range

Shaft Dia : 12 to 100 mm
pressure : 6 bar(max)
Temperature : -20 to +140C
Velocity : Up to 20 m/sec

  Features

Single Acting | Unbalanced | Inside Mounted
Independent of Direction of Rotation
Wave Spring Loaded
